低频超声作用下体外实验草酸钙晶体的大小及形态变化

赵振华; 叶向东; 吴文起; 曾国华

doi:10.13201/j.issn.1001-1420.2014.02.021

低频超声作用下体外实验草酸钙晶体的大小及形态变化

- 广州医科大学附属第一医院微创外科中心泌尿外科, 广东省泌尿外科重点实验室(广州, 510230)
基金项目:
广东省科技计划项目(编号2010A030300009)

广州市民生科技重大专项项目(编号201300000096)

详细信息

通讯作者: 曾国华, E-mail:gzgyzgh@vip.tom.com

中图分类号: R691.4

收稿日期: 2013-08-28

Influence of low-frequency ultrasound on size and morphology of calcium oxalate crystal in vitro

- Department of Urology, Minimally Invasive Surgery Center, First Affiliated Hospital of Guangzhou Medical University, Guangdong Key Laboratory of Urology, Guangzhou, 510230, China

More Information

Corresponding author: ZENG Guohua, E-mail: gzgyzgh@vip.tom.com

Received Date: 28 August 2013

摘要

摘要: 目的: 研究低频超声作用下,体外实验中草酸钙晶体的大小及形态变化。方法: 配置氯化钙和草酸钠溶液作为反应初始溶液,在(37±0.5)℃恒温水浴箱,将两者按3个不同浓度分别混合后得到草酸钙晶体。实验分超声组和对照组,超声组置入低频超声波清洗机(超声发生频率:40 kHz)内槽,固定超声功率(330 W,对应超声声强为0.5W/cm²)及作用时间(15 min)加以作用;对照组不加处理,相同时间下自然结晶。晶体形成后通过光镜和电镜观察草酸钙晶体的形态及直径。结果: 3个浓度下,超声组处理后得到的草酸钙晶体直径均明显较对照组小,差异有统计学意义(P<0.05),且超声作用效果随着反应物浓度的增加而逐渐增强。草酸钙晶体形态在超声作用后改变不明显。结论: 低频超声对体外实验草酸钙晶体的直径有明显的抑制作用。
- 低频超声 /
- 草酸钙晶体 /
- 泌尿系结石 /
- 体外实验
Abstract: Objective: To study the influence of low-frequency ultrasound on size and morphology of calcium oxalate crystals in vitro. Method:CaCl₂ and Na₂C₂O₄ solutions at three molar concentrations were mixed at (37 ± 0.5)℃ water in order to obtain calcium oxalate crystals. There were two groups. In the ultrasound group, two reaction solutions were irradiated by a low-frequency ultrasonic cleaning machine (Rated frequency:40 kHz; power:330W, corresponding to 0.5W/cm² in ultrasonic intensity) for 15 minutes. In the control group, CaCl₂ and Na₂C₂O₄ solutions were mixed and reacted without treatment at the same time. The calcium oxalate crystals were collected and then observed with inverted light microscopy and scanning electron microscopy (SEM), and the crystal morphology and diameter were observed and measured. Result:The diameter of calcium oxalate crystals in the ultrasound group were significantly smaller than the control group (P<0.05), and the ultrasonic effect became strengthened along with the increasing concentration of reactants. However, there were no obvious morphological changes. Conclusion: In vitro experimental conditions, low-frequency ultrasound can significantly inhibit the diameter of calcium oxalate crystals.Key words low-frequency ultrasound; calcium oxalate crystals; urinary stones; in vitro
- low-frequency ultrasound /
- calcium oxalate crystals /
- urinary stones /
- in vitro

HTML全文

参考文献(16)

[1]	Moe O W.Kidney stones:pathophysiology and medical management[J].Lancet, 2006, 367 (9507):333-344.
[2]	Trinchieri A, Ostini F, Nespoli R, et al.A prospective study of recurrence rate and risk factors for recurrence after a first renal stone[J].J Urol, 1999, 162 (1):27-30.
[3]	Sutherland J W, Parks J H, Coe F L.Recurrence after a single renal stone in a community practice[J].Miner Electrolyte Metab, 1985, 11 (4):267-269.
[4]	谢彩锋, 丘泰球, 陆海勤, 等.超声作用下碳酸钙晶体的形态变化[J].华南理工大学学报 (自然科学版), 2007, 35 (4):62-66.
[5]	Alonso D, Pieras E, PizáP, et al.Effects of short and long-term indapamide treatments on urinary calcium excretion in patients with calcium oxalate dihydrate urinary stone disease:A pilot study[J].Scand J Urol Nephrol, 2012, 46 (2):97-101.
[6]	Miyaoka R, Monga M.Use of traditional Chinese Medicine in the management of urinary stone disease[J].Int Braz J Urol, 2009, 35 (4):396-405.
[7]	杨少玲, 胡兵.低频超声在治疗中的应用[J].中华超声影像学杂志, 2012, 21 (1):79-81.
[8]	Hitchcock K E, Holland C K.Ultrasound-assisted thrombolysis for stroke therapy:better thrombus break-up with bubbles[J].Stroke, 2010, 41 (10 Suppl):S50-S53.
[9]	Meunier J M, Holland C K, Pancioli AM, et al.Effect of low frequency ultrasound on combined rt-PA and eptifibatide thrombolysis in human clots[J].Thromb Res, 2009, 123 (3):528-536.
[10]	Siegel RJ, Atar S, Fishbein MC, et al.Noninvasive transcutaneous low frequency ultrasound enhances thrombolysis in peripheral and coronary arteries[J].Echocardiography, 2001, 18 (3):247-257.
[11]	Rubin C, Bolander M, Ryaby JP, et al.The use of low-intensity ultrasound to accelerate the healing of fractures[J].J Bone Joint Surg Am, 2001, 83-A (2):259-270.
[12]	Ramli R, Reher P, Harris M, et al.The effect of ultrasound on angiogenesis:an in vivo study using the chick chorioallantoic membrane[J].Int J Oral Maxillofac Implants, 2009, 24 (4):591-596.
[13]	Sergeeva N S, Sviridova I K, Nikolaev A L, et al.Effects of various modes of sonication with low frequency ultrasound on in vitro survival of human tumor cells[J].Bull Exp Biol Med, 2001, 131 (3):279-282.
[14]	Tabuchi Y, Takasaki I, Zhao Q L, et al.Genetic networks responsive to low-intensity pulsed ultrasound in human lymphoma U937 cells[J].Cancer Lett, 2008, 270 (2):286-294.
[15]	Stoica-Guzun A, Stroescu M, Jinga S, et al.Ultrasound influence upon calcium carbonate precipitation on bacterial cellulose membranes[J].Ultrason Sonochem, 2012, 19 (4):909-915.
[16]	Thongboonkerd V, Semangoen T, Chutipongtanate S.Factors determining types and morphologies of calcium oxalate crystals:molar concentrations, buffering, pH, stirring and temperature[J].Clin Chim Acta, 2006, 367 (1-2):120-131.
